Marshall CV574-WP All-Weather 4K NDI|HX3 Camera
The Marshall CV574-WP is a compact all-weather 4K network camera designed for demanding broadcast, live production, sports, outdoor streaming, and professional AV applications. Its IP67-rated aluminum-alloy housing and weatherproof breakout cable make it well suited to installations where exposure to moisture, dust, and harsh conditions is a concern.
At the heart of the CV574-WP is an 8.46-megapixel 1/2.8" UHD CMOS sensor capable of delivering up to 3840 × 2160p60 over IP. The camera supports NDI|HX3 and NDI|HX2 along with SRT, RTSP, and RTMP streaming, providing flexible integration into modern network production environments.
The interchangeable M12 lens mount comes with a 4.0mm lens providing approximately a 77° horizontal angle of view, while optional M12 lenses allow the camera to be adapted for different shooting distances and coverage requirements.
Key Features
-
8.46MP 1/2.8" UHD progressive CMOS sensor
-
Up to 3840 × 2160p60 video over IP
-
IP67-rated weatherproof construction
-
Durable aluminum-alloy camera body
-
Interchangeable M12 lens mount
-
Includes 4.0mm lens with approximately 77° horizontal AOV
-
NDI|HX3 and NDI|HX2 support
-
SRT, RTSP, and RTMP streaming
-
H.264 and H.265/HEVC encoding
-
NDI|HX3 supports 1080p50/60
-
Audio input for embedding audio into the video stream
-
VISCA over IP control
-
Web-based camera control interface
-
PoE support for single-cable network installation
-
Included 12V DC power supply
-
10-foot / 3-meter weatherproof breakout cable
-
Standard 1/4"-20 mounting point
-
Day/Night operation with improved low-light performance
Technical Specifications
Sensor: 1/2.8" Progressive CMOS
Effective Pixels: 3840 × 2160
Sensor Resolution: Approximately 8.46MP
Lens Mount: M12
Included Lens: 4.0mm
Horizontal AOV: Approximately 77°
Maximum IP Video: 3840 × 2160p60
NDI: NDI|HX2 / NDI|HX3
NDI|HX3 Output: 1080p50/60
Streaming Protocols: NDI|HX2, NDI|HX3, SRT, RTMP, RTSP
Codecs: H.264 / H.265 HEVC
Audio: Line-level input, 16kHz / 32kHz / 48kHz
Control: Web GUI / VISCA over IP
Power: 12V DC or PoE
Weather Protection: IP67
Operating Temperature: -10°C to 50°C
Dimensions: 113.45 × 55 × 61mm
Weight: 1.65 lb
Professional Applications
The CV574-WP is designed for outdoor broadcast, live sports, concerts, REMI production, newsgathering, eSports, reality television, courtroom capture, government assemblies, corporate video, live performance, and houses of worship where reliable 4K network video is required in challenging environments.
