New from Lavry, the AD-24-200 Savitr provides improved quality, and ease of use for the most technically demanding recording and mastering studios.
This frankly astonishing converter outperforms our previous AD122 series converters across the board. The Savitr grants low distortion which redefines the industry standard. It extends the clock range to include 192 kHz, and automates the search for external clock signals.
*The Savitr also offers a 2nd digital audio output with independent user control over audio formats and clocking to either internal or external clock sources.
COMPARISON TO LEGACY PRODUCTS
Key features
FEATURES INCLUDE:
✓ Pristine audio performance (THD+N) up to 200 kHz sample rate
✓ Intuitive operation
✓ High-resolution meter display
✓ Main & Auxiliary digital outputs
♪ Independent audio formats (AES/SPDIF)
♪ Independent clocking (Search & Lock/ Internal)
✓ User
♪ MX clipping (on/off)
♪ Soft saturation levels (4)
♪ Low Latency mode (on/off)
Tech specs
PERFORMANCE
THD+N (0 dB Internal Gain)
Analog Input Level |
Source Frequency |
Gain |
20 kHz Bandwidth |
40 kHz Bandwidth |
-1 dBFS |
1 kHz |
0 dB |
-110 dBFS |
0.00032 %FS |
-107 dBFS |
0.00045 %FS |
-0.1 dBFS |
20 Hz to 20 kHz |
0 dB |
-109 dBFS |
0.00035 %FS |
-103 dBFS |
0.00071 %FS |
-1 dBFS |
20 Hz to 20 kHz |
0 dB |
-109 dBFS |
0.00035 %FS |
-106 dBFS |
0.00050 %FS |
-3 dBFS |
20 Hz to 20 kHz |
0 dB |
-113 dBFS |
0.00022 %FS |
-110 dBFS |
0.00032 %FS |
THD+N (with Internal Gain)
6 dB of Internal Gain: Increases THD+N by less than 2dB of the values above.
Dynamic Range
Sample Rate |
Bandwidth |
Unweighted |
A-Weighted |
44.1 kHz |
20 kHz |
126 dBFS |
128 dBFS |
96 kHz |
40 kHz |
122 dBFS |
128 dBFS |
192 kHz |
80 kHz |
104 dBFS |
128 dBFS |
Channel Separation
- 1 kHz: 123dBFS
- 20-20 kHz: 108dBFS
Latency
|
Main Output |
|
AUX Output |
Conversion Rate |
Best Quality |
Low Latency |
Auxiliary Rate |
Best Quality |
Low Latency |
44.1 kHz |
471 µs |
153 µs |
44.1 kHz |
3.7 ms |
3.5 ms |
48 kHz |
440 µs |
150 µs |
48 kHz |
3.4 ms |
3.4 ms |
88.2 kHz |
267 µs |
109 µs |
88.2 kHz |
1.9 ms |
1.7 ms |
96 kHz |
249 µs |
103 µs |
96 kHz |
1.7 ms |
1.6 ms |
176.4 kHz |
137 µs |
89 µs |
176.4 kHz |
940 µs |
890 µs |
192 kHz |
130 µs |
86 µs |
192 kHz |
865 µs |
820 µs |
