HEDD TYPE 20 MK2 Studio Monitor, 3-way, 3x300W with DSP

Sale price$ 2,399.00

Color: Black


Layout: Left


Call us at 1-877-223-8858 or Ask a Question below

HEDD TYPE 20 MK2 Studio Monitor, 3-way, 3x300W with DSP


HEDD TYPE 20 MK2 Studio Monitor, 3-way, 3x300W with DSP

Combine openness, punch, a gloriously honest midrange clarity, and a jaw-dropping low end performance and you have the Type 20 monitor. The perfect all-rounder. The perfect companion for every audio endeavor. From producing bass-hungry beats to mastering the most sophisticated Jazz records: This 3-way monitor will unveil new layers in your music and transport your engineering skills to the next level.


  • 7” woofer
  • Dedicated 4” midrange driver
  • High definition HEDD Air Motion Transformer
  • Powerful SHARC-DSP and onboard LineariserR flatten speaker phase and create fascinating stereo image and depth
  • Closed or Ported functionality for two distinct sound experiences: accurate and detailed (closed) or energetic and bassy (ported)
  • Complete linear phase Satellite-Subwoofer setup with BASS 12 subwoofers
  • Desktop and shelving filters
  • Bass-extension mode
  • Stepped aluminum pot controls
  • 3 year warranty when you register your product with us


  • Main Features
    HEDD Lineariser®, CoP, GDC, LFE, Desk and Shelf Filters
  • Dimensions
    280 x 358 x 338 mm
  • Weight
    15.4 kg per unit
  • DSP Integration
    Custom high-resolution 96 kHz / 32 Bit AD / DA converter
  • Drivers
    3-Way: Proprietary 7" and 4" Honeycomb Woofers, HEDD AMT Tweeter
  • Power
    3x300 W ICEpower amplification (85-264 V)
  • Crossovers
    250 Hz / 3.200 Hz
  • Frequency Range
    32 Hz - 40 kHz (LFE: 26 Hz - 40 kHz)
  • Maximum SPL
    SPL 120 dB SPL (sound pressure level) per pair at 1m
  • Inputs
    Analog (XLR / 22 kΩ) and Digital 2ch (AES / XLR)
  • Output
    Digital AES pass-through via XLR
