The 15 Amp P-1800 AR delivers a stable 120 volts of AC power to protect equipment from problems caused by AC line voltage irregularities such as sags, brownouts, or overvoltages - all of which can cause sensitive electronic equipment to malfunction or sustain damage. The P-1800 AR accepts input voltages over a wide AC voltage range and transforms it to a constant output of 120V, ±5V. Voltages beyond that range may also be converted to usable levels, depending on the range variance.
Additionally, the P-1800 AR is a full-featured power conditioner that filters and purifies AC power, reducing line noise and ensuring optimum performance. Not only will your equipment perform better with Furman’s Linear Filtering Technology (LiFT), but it will also be fully protected by our exclusive Series Multi-Stage Protection (SMP), and Extreme Voltage Shutdown (EVS). This circuitry provides the highest level of power protection available.
|Maximum Current:||15 amps @ 124 Volts|
|Line Cord:||Captive 3/14 AWG, 10 ft. black cord with NEMA 15 plug|
|BNC Socket w/Switch:||12VAC 500MA maxx (lamp not included)|
|Operating Voltage:||90 to 139 VAC|
|Over-Voltage Shutdown:||140 VAC Nominal|
|Approximate Input Voltage Capture Range:||97 to 137 VAC|
|Spike Protection Mode:||Line to neutral, zero ground leakage|
|Spike Clamping Voltage:||188 VAC peak @ 3,000 Amps|
|Response Time:||1 nanosecond|
|Maximum Surge Current:||6,500 Amps|
|Noise Attenuation:||10 dB @ 10 kHz, 40 dB @ 100 kHz, 50 dB @ 500 kHz|
|Dimensions:||19” W x 12” D x 1.75” H|
|Power Consumption:||5 watts|
