Augspurger Duo 15V Passive Main Monitors, PAIR
Talk to an Expert
Passive vertical 2 X 15 cabinet with drivers - no amps/crossovers. PAIR
The Duo 15 incorporates a pair of dual 15” drivers with a compression driver feeding a hardwood horn in a VERTICAL DʼAppolito array for precise imaging and optimal phase coherency.
The cabinets feature Augspurgerʼs proprietary drivers, which are the result of years of design, field testing and refinement. The end result is a system that is extremely accurate and linear, while providing power and impact like no other monitoring system. Optional Class-D amplifiers are available to create power up to 2500W per side.
Free-standing or soffitable.
Subwoofers are available in 1X18 and 2X18 sizes.
-
2x15" Vertical Cabinet with dual 15" low freqency drivers, Compression driver with 4" voice coil and 2" throat with beryllium diaphragm feeding proprietary wooden horn. 47.5"H x 26W" x 18”D. cm: 120.65 x 66.04 x 45.72
The speakers come standard in a matte black finish and matte silver at no upcharge, Custom high gloss automotive paint finishes are available in any color to complement your room decor. Call for custom paint pricing.
Breathtaking Power. Unmistakable Clarity
Description:
2-way actively powered Main Monitor with dual 15” LF/Mid drivers and wooden horn, with on-board
DSP for system voicing. Optional 3-way amp to power LF/Subwoofer via Speakon NL2 connection
Cabinet Materials:
1.5” High density fiberboard baffle, 1” high density fiberboard sides and back, recycled cotton fiber
fill.
Horn:
Single cut, rock maple for painted cabinets, figured Big Leaf Maple for wood finished horns,
machine milled, hand assembled and finished.
HF Driver:
4” 99.8% Pure beryllium diaphragm by TruExtent, powered by neodymium compression driver with
ultra-low distortion capable of 125w RMS/250w program for exceptionally high SPL without
distortion, 16 ohm, 104db sensitivity.
LF/MF Driver:
15” Carbon fiber loaded paper cone, sanoprene surround, conex spider woofer with ferrite magnet,
11.0 mm X max, 700W RMS / 1200 program, 8 ohm.
Amplifiers:
2-Way systems: DSP-2 2-way D-Class ultra-low distortion, high output amplifier with DSP
controlled crossover, eq, phase, driver alignment, limiting (user optional) and level control. HF amp
channel with 150w at 16 ohm, LF channel with 600w at 8 ohm
3-Way systems: DSP-3 3-way D-Class ultra-low distortion, high output amplifier with DSP
controlled crossover, eq, phase, driver alignment, limiting (user optional) and level control. HF amp
channel with 150w at16 ohm, MF channel with 600w at 8 ohm, LF/Sub channel with 1100w at 4
ohm
Control: Software: Via USB with proprietary PC Software offering 16 FIR user definable EQ Filters
per band, Phase Alignment, Time alignment of each band, limiting and level control.
Frequency Response: 25Hz - 20kHz ±3db, no sub.
SPL: 125db without sub, 135db with 18” sub
AC Power Input: 110 to 240 Auto sensing, internally fused
Cooling: Convention cooled, rear mounted heat sinks, no fans
Weight: 180lbs each without amps, 196lbs each with amps
Shipping weight: 200lbs each without amps, 220lbs with amps
Cabinet Dimensions: 47.5"H x 26W" x 18”D. cm: 120.65 x 66.04 x 45.72
